Description

General technical data
Valve function 3/2-way, single solenoid
Design Poppet seat
Overlap Negative overlap
Sealing principle Soft
Actuation type Electrical
Reset method Mechanical spring
Type of control Piloted
Pilot air supply Internal or external
Flow direction Non-reversible (reversible/reversible with restrictions with external pilot air supply)
Exhaust function Can be throttled
Manual override Detenting
Type of mounting Via through-hole or on manifold rail/manifold block1)
Mounting position Any
Electrical connection Via F solenoid coil, to be ordered separately
Port for venting hole M5 (only ATEX types)
Pilot exhaust air port 82/84 M5
Pilot air port 12 M5
